Pipe Size: 2-4 in / 50-100 mm
Max Flow: 8 gpm / 30 l/min
Inlet: 1/4" NPT or BSPP
Pipe Size: 3-6 in / 80-150 mm
Max Flow: 21 gpm / 80 l/min
Inlet: 3/8" & 1/2" NPT or BSPP
Pipe Size: 4-8 in / 100-150 mm
Max Flow: 21 gpm / 80 l/min
Inlet: 1/2" NPT or BSPP
Pipe Size: 3-8 in / 80-200 mm
Max Flow: 21 gpm / 80 l/min
Inlet: 3/8" & 1/2" NPT or BSPP
Pipe Size: 6-18 in / 150-450 mm
Max Flow: 70 gpm / 265 l/min
Inlet: 3/4" & 1" NPT or BSPP
Pipe Size: 8-36 in / 200-900 mm
Max Flow: 120 gpm / 450 l/min
Inlets: 1" & 1-1/4" NPT or BSPP
Fixed nozzles can leave strips of untouched pipe wall. Warthog controlled rotation helps water reach the full circumference of the pipe at a speed that gives the jets time to work. That means crews are not just opening a path through the blockage. They are cleaning the pipe wall.
More water does not automatically mean better cleaning. Warthog nozzles are designed to put water where it matters: on the deposit and against the pipe wall. Controlled rotation and matched jetting help reduce wasted water from poor coverage or repeated passes.
Fuel cost is tied to pump time, engine load and how long the crew stays on site. When the nozzle cleans more effectively per pass, crews can reduce unnecessary run time. The result is a more efficient job cycle and better use of the truck, pump and water supply.
A nozzle that clears the blockage but leaves build up behind creates extra work. Warthog tools help crews clean, cut and flush in a single operation. That improves labour efficiency because operators spend less time fighting the same obstruction and more time completing the line.
The practical advantage is simple: better impact, better coverage and fewer wasted passes can increase the amount of pipe a crew can clean in a day. Instead of measuring productivity only by gallons per minute or pressure, Warthog helps crews focus on cleaned pipe per hour.
Roots, grease, sediment and scale do not fail the same way. Warthog gives crews different nozzle families, jet angles and configurations so the nozzle can be matched to the blockage, pipe size and pump output.
Warthog nozzles are engineered for demanding sewer and drain cleaning, from routine maintenance and small laterals to commercial lines and large municipal pipe. Magnum options add durability for high-demand applications, while multiple sizes help crews tackle more jobs.
Water, fuel, and labor are the biggest operating costs in jetting. Warthog improves the return on each gallon by applying water with controlled rotation, targeted impact. The outcome is not just more force, it's more useful cleaning energy delivered to the pipe.
